What Factors Will Affect the Drying Condition for Catalogue Printing?
Drying is one of those steps in catalogue printing that people don’t think about until something goes wrong. Most of these problems are due to poor drying conditions, such as the ink on the cover, the page being sticky, and the color after binding. So today, I explain what actually controls how fast and how well ink dries on a printed catalogue. And why it matters so much for the final product you hold in your hands.
Why Drying Matters So Much in Catalogue Printing
A catalogue goes through many steps after printing, folding, trimming, binding, and packing. So if the ink isn’t fully dry before these steps start, you get set-off marks, blurry text, or pages sticking together. For a product that symbolizes a brand, this is a mistake that leads to great losses. By performing appropriate drying treatment, the page can be kept clean, bright color can be kept, and the catalog can be shipped on time.
1. Pressroom Temperature and Humidity
Here, temperature and humidity are two major factors. If the printing room is too cold, the chemical reaction to settle the ink will be significantly slower and the page will remain in a longer and stickier state. Warm air promotes drying. On the other hand, humidity has almost the opposite effect. Moist air prevents proper evaporation of solvents and traps moisture in the ink layer. However, it is not good if the air is too dry. Static electricity occurs, causing the edge of the paper to defy or become fragile.
Most printers aim to keep the temperature in the printing room from 20 °C to 24 °C and humidity from 40% to 60%. By maintaining this balance, the paper condition can be stabilized so that the ink can be prevented and the binding work can be done smoothly.
2. Airflow around the Press
Even with the right temperature and humidity, drying can stall if the air isn’t moving. So if there is a good air flow, the solvent vapor and moisture are discharged from the printed paper and the space for the ink to settle is secured. And if the exhaust or ventilation system in the printing room is not fully functional, the steam accumulates around the paper and delays the entire process. In some cases, the effect is severe, and it can have a negative effect on the entire printing lot.
3. Type of Ink Used
Not all inks dry the same way. Standard offset ink dries through a mix of absorption into the paper and a slow reaction with oxygen in the air. On the other hand, UV curing ink is completely different. Because it hardens almost instantly under UV light, this ink is widely adopted in catalog printing of mass production to speed up the process. Also, the coating thickness of the ink has a significant effect on drying. The thicker the coating thickness of the ink, the more moisture is trapped beneath it, so it takes time to dry and it becomes easier to handle it too early.
4. Paper Type and Its Absorption Rate
The drying speed varies greatly depending on the type of paper you choose. Coated paper and glossy paper take time to dry because ink is fastened to the surface instead of soaking it into paper. On the other hand, non-coated paper is porous, inhaling ink like a sponge, which naturally makes drying faster. Acidity of paper is also an important factor. If the acidity of the paper is too high, the work of the desiccant of the ink may be prevented, and the ink may not dry on the page and unevenness may remain.
5. Fountain Solution and Press Settings
On an offset press, the fountain solution keeps ink confined to the right areas of the plate. If that solution becomes too acidic, it can break down the drying agents mixed into the ink, leading to wet spots even after the sheet leaves the press. Printers who monitor and adjust their fountain solution regularly avoid a lot of this trouble before it starts.
6. How Sheets Are Stacked After Printing
Once catalogues come off the press, how they’re handled matters just as much as how they were printed. Stacking wet sheets too high blocks air from reaching the middle of the pile, so ink stays damp far longer than expected. Printers usually stack in shorter lifts and use anti-set-off powder between sheets to stop ink from transferring onto the next page while everything finishes drying.
Getting It Right Makes All the Difference
The proper drying depends on the control of temperature, humidity, air flow, ink selection, paper type, and handling methods at the same time. If one of these is neglected, there is a risk of smudged pages, wasted stock, and delayed delivery.
